Machine Facility
List Of Machines Foundry Unit
| No | Item Description | Quantity |
|---|---|---|
| 1 | Plasma Induction 250kw – 300 Kg & 500 kg Induction furnace | 1 Nos |
| 2 | 300 kg Sand Mixer with Cooler installation | 1 Nos |
| 3 | 150kg Sand Mixer | 2 Nos |
| 4 | Pneumatic Moulding Machine ARPA-300 | 2 Nos |
| 5 | Pin lift Type Moulding Machine | 4 Nos |
| 6 | Sand Plant with 50T capacity sand hopper | 1 Nos |
| 7 | 200kg Geared Tea pot Poring Laddles | 3 Nos |
| 8 | 200kg Treatment Laddles | 1 Nos |
| 9 | Cold box core making | 1 Nos |
| 10 | Hanger type shot blasting machine 300Kg capacity | 1 Nos |
| 11 | Pedestal Grinders | 3 Nos |
| 12 | 20HP Air compressor | 1 Nos |
Testing Equipment
| # | Item Description | Quantity |
|---|---|---|
| 1 | Carbon Silicon Analyzer | 1 Nos |
| 2 | Metal vision 108N Spectrometer | 1 Nos |
| 3 | Microscope | 1 Nos |
| 4 | Mould Hardness tester | 1 Nos |
| 5 | Temperature measurement | 1 Nos |
| 6 | Brinell Hardness Testing Machine | 1 Nos |
| 7 | Moisture tester | 1 Nos |
| 8 | Permeability tester | 1 Nos |
| 9 | Scratch Hardness Tester | 1 Nos |
Spectro Meter & Micro Meter Lab
Hardness Testing Machine & Sand Testing Lab
Measuring Instrument
| No. | Item Description | Quantity |
|---|---|---|
| 1 | Trimos – Electra Optima 600 | 1 Nos |
| 2 | Vernier Caliper (Mitutoyo) 12” & 5” | 5 Nos |
| 3 | Vernier Depth Caliper (Mitutoyo) 6” | 1 Nos |
| 4 | Bore Dial Gauge 50 to 150mm | 10 nos |
| 5 | Pistol caliper | 1 Nos |
| 6 | Surface Plate 3’ x 4’ | 4 Nos |
| 7 | Surface Tester | 1 Nos |
Machine Shop Unit
| No. | Item Description | Quantity |
|---|---|---|
| 1 | Vertical Machining Centre(BFW- 45 TC20 – Size 650X450X500) | 1 Nos |
| 2 | Vertical Machining Centre(BFW- 51 TC20 with APC- Size 650X450X500) | 1 Nos |
| 3 | Vertical Machining Centre(Lokesh -TC24 Size 850X550X500) | 1 Nos |
| 4 | Vertical Machining Centre(Lokesh -BT40 TC24 Size 600X300X250) | 1 Nos |
| 5 | Vertical Machining Centre(Lokesh -VM9-BT40 TC24 Size 1000X500X500) | 1 Nos |
| 6 | Milling Machine (Rajkot & HMT) | 3 Nos |
| 7 | Radial Drilling Machine (¾” Spindle) | 4 Nos |
| 8 | Tapping Machine – 12mm | 1 Nos |
